Kubota
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 5,512 lb |
|---|---|
| Fuel Capacity | 29.1 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 4,630 lb |
| 3 Point Hitch Type | Cat II |
| Turning Radius | 162 in |
| Alternator Supplied Amperage | 45 A |
| Operating Voltage | 12 V |
| Tire Size Front - 2wd / 4wd | 7.50-18 |
Engine
| Engine Model | V3800TIE2 |
|---|---|
| Displacement | 230 in³ |
| Power Measured @ | 2,600 rpm |
| Net Power | 94.5 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| PTO Power | 84.0 hp |
Hydraulic System
| Pump Flow Capacity | 17.0 gal/min |
|---|---|
| Number of Remote Control Valves | 1 |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 102 in |
| Wheelbase | 89 in |
| Overall Width | 76 in |
| Tire Size | front 12.4-24 rear 18.4-30 |
| Width Outside Frame | 76 in |
| Height - Top of ROPS/FOPS | 102 in |
Transmission
| Max Speed | 20.9 mph |
|---|---|
| Number of Forward Gears | 8 |
| Transmission Type | synchronized shift |
| Number of Reverse Gears | 8 |
Tires & Wheels
| Rear Tires Size | 18.4-30 |
|---|
