Kubota

M95X

Tractor

Operating Weight
9,050 lb
Displacement
230 in³
Power Measured @
2,600 rpm
All tractors
Kubota M95X Tractor
1 / 5
Image 1 of 5
Image: tractordata.com

Specifications

24 data points

Operating Specifications

Operating Specifications specifications
Operating Weight9,050 lb
Fuel Capacity50.2 gal
3 Point Hitch Lift Capacity @ 24 inches5,203 lb
3 Point Hitch TypeCat II
Turning Radius158 in
Alternator Supplied Amperage80 A
Operating Voltage12 V

Engine

Engine specifications
Engine ModelV3800TE2
Displacement230 in³
Power Measured @2,600 rpm
Net Power95.0 hp
Number of Cylinders4
Aspirationturbocharged
PTO Power80.0 hp

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity18.1 gal/min
Number of Remote Control Valves2

Dimensions

Dimensions specifications
Wheelbase96 in
Overall Length14 in
Tire Sizefront 12.4R24 rear 18.4R30
Width Outside Frame84 in

Transmission

Transmission specifications
Max Speed21.2 mph
Number of Forward Gears16
Transmission TypeIntelli-Shift dual-range power shift
Number of Reverse Gears16
