Liebherr
Terex
ATT 400
All Terrain Crane
25 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Tire Size | 14.00 R 25 |
|---|---|
| Carrier Fuel Capacity | 79.3 gal |
| Operating Voltage | 24 V |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Transport Width | 100 in |
| Transport Height | 141 in |
| Transport Length | 396 in |
| Width w/ Outriggers Extended | 236 in |
| Upper Structure Tail Swing Radius | 125 in |
| Carrier Length | 330 in |
Transmission
| Transmission Type | ZF Powershift |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Boom
| Number of Sections | 4 |
|---|---|
| Max Height @ Max Raise Angle - no jib | 1,182 in |
| Min Height @ Max Raise Angle | 362 in |
CARRIER ENGINE
| Gross Power | 275.0 hp |
|---|---|
| Max Torque | 811 lb-ft |
| Torque Measured @ | 1,500 rpm |
| Make | Liebherr |
| Power Measured @ | 2,300 rpm |
