ATT 400
All Terrain Crane
25 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Tire Size | 14.00R25 |
|---|---|
| Carrier Fuel Capacity | 158.6 gal |
| Operating Voltage | 24 V |
| Upper Structure Fuel Capacity | 66.1 gal |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Transport Width | 119 in |
| Transport Height | 156 in |
| Transport Length | 696 in |
| Width w/ Outriggers Extended | 335 in |
| Upper Structure Tail Swing Radius | 221 in |
| Carrier Length | 615 in |
Transmission
| Transmission Type | Allison CLBT755 |
|---|---|
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 1 |
Boom
| Number of Sections | 6 |
|---|---|
| Max Height @ Max Raise Angle - no jib | 2,835 in |
| Min Height @ Max Raise Angle | 607 in |
CARRIER ENGINE
| Gross Power | 590.1 hp |
|---|---|
| Max Torque | 1,918 lb-ft |
| Torque Measured @ | 1,400 rpm |
| Make | Liebherr |
| Power Measured @ | 1,900 rpm |
UPPER STRUCTURE ENGINE
| Gross Power | 241.4 hp |
|---|---|
| Make | Liebherr |
| Max Torque | 797 lb-ft |
| Torque Measured @ | 1,150 rpm |
| Power Measured @ | 1,800 rpm |
