Link Belt
Liebherr
LR-1110
Crawler Crane
Specifications pending
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Fuel Capacity | 76.7 gal |
|---|---|
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 78.0 gal |
Engine
| Engine Model | 6SA1T |
|---|---|
| Power Measured @ | 2,100 rpm |
| Net Power | 263.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 513 lb-ft |
| Engine Make | Isuzu |
| Stroke | 5 in |
| Bore | 5 in |
| Battery | 2 |
Dimensions
| Ground Clearance | 48 in |
|---|---|
| Tail Swing Radius | 162 in |
| Transport Width | 131 in |
| Transport Height | 214 in |
| Gradeability | 30.0 % |
Transmission
| Max Speed | 1.1 mph |
|---|
Undercarriage
| Width of Shoes | 36 in |
|---|---|
| Number of Shoes per Side | 50 |
| Number of Track Rollers per Side | 10 |
