Massey Ferguson 1844S Baler
1 / 5
Image 1 of 5
Image: powelltractor.com

Specifications

25 data points

Engine

Engine specifications
Electrical System12 V DC

Dimensions

Dimensions specifications
Overall Width104 in
Weight5,706 lb
Tractor PTO Power Required80.5 hp
Length w/bale chute285 in
Height w/shielding69 in

Tires & Wheels

Tires & Wheels specifications
Standard14L x 16.1 12 Ply

Bale Size

Bale Size specifications
Bale Length - max53 in
Bale Length - min13 in
Bale cross section,Height X Width(in,mm)15 x 22 (380 x 560)
Baler weight8,007 lb

Baler Pickup

Baler Pickup specifications
Overall Width109 in
Number of Bars4
Tine to Tine Width71 in
Number of Tines56
Inside Width78 in
Tine spacing3 in
Pickup gauge wheel4.00 x 16 pneumatic w/ inner tube
Outer tine-to-tine width91 in
Pickup liftHydraulic cylinder
Pickup protectionSlip & overrunning clutch

Feeding Chamber

Feeding Chamber specifications
Stuffer Type6 Crank tines
ProtectionShearbolt

Plunger

Plunger specifications
Stroke Length22 in
Plunger speed (strokes/min)90
