Massey Ferguson
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Fuel Capacity | 14.6 gal |
|---|
Engine
| Engine Model | 2605H |
|---|---|
| Displacement | 159 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 55.0 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
| Engine Make | Simpson |
| PTO Power | 46.0 hp |
| Emissions Certification | External cooled exhaust gas recirculation (EGR) with diesel oxidation catalyst (DOC) |
| EPA | EPA Tier 4 |
Hydraulic System
| Pump Flow Capacity | 15.8 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Hydraulic System Type | Open Center and Modified Closed Center |
| Pump Type | Gear and Scotch Yoke |
| Auxiliary hydraulic flow | 10.6 gal/min |
Dimensions
| Wheelbase | 81 in |
|---|---|
| Overall Length | 139 in |
| Overall Width | 67 in |
| Overall Height | 93 in |
| ROPS base weight without ballast | 5,393 lb |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Number of Reverse Gears | 2 |
| Brake type | Drum brakes |
Production
| Series | 2600H Series |
|---|---|
| Years Manufactured | — |
Axles
| Front | 4WD HD planetary reduction |
|---|---|
| Rear | Direct drive |
| Differential lock | Mechanical engagement via right-side heel pedal |
3-Point Hitch
| Lift capacity @ 24in. (ASAE) | 2,205 lb |
|---|---|
| Extendable lower links | Optional |
Power Take-Off (PTO)
| Power Take-Off(PTO) Type | Dry Dual Disc |
|---|---|
| PTO speed | 540 rpm |
| Optional | Independent |
| Standard | Live |
