Massey Ferguson

2706E

Tractor

Displacement
134 in³
Power Measured @
2,600 rpm
Gross Power
57.3 hp
All tractors
Massey Ferguson 2706E Tractor
1 / 5
Image 1 of 5
Image: allmachines.com

Specifications

25 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity14.0 gal

Engine

Engine specifications
Engine ModelN4LDI-TA
Displacement134 in³
Power Measured @2,600 rpm
Gross Power57.3 hp
Number of Cylinders4
AspirationLiquid-cooled
Engine MakeShibaura
PTO Power48.7 hp

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity12.4 gal/min
Hydraulic System TypeOpen Center system
Pump TypeGear type single pump

Dimensions

Dimensions specifications
Wheelbase78 in
Overall Length133 in
Overall Width76 in
Height - Top of ROPS/FOPS104 in

Production

Production specifications
Series2700E Series
Years Manufactured2,016 – 2,019

Electrical System

Electrical System specifications
Alternator90
Battery12 V

3-Point Hitch

3-Point Hitch specifications
Lift capacity @ 24in. (ASAE)2,425 lb

Power Take-Off (PTO)

Power Take-Off (PTO) specifications
Power Take-Off(PTO) TypeElectro-hydraulically engaged
PTO speed540 rpm
OptionalIndependent
StandardLive
