Massey Ferguson
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
17 data points
Operating Specifications
| Operating Weight | 6,118 lb |
|---|---|
| Fuel Capacity | 17.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,512 lb |
Engine
| Power Measured @ | 2,000 rpm |
|---|---|
| Gross Power | 94.0 hp |
| Number of Cylinders | 3 |
| Max Torque | 288 lb-ft |
Hydraulic System
| Pump Flow Capacity | 16.4 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
| Maximum operating pressure | 2,756 psi |
Dimensions
| Wheelbase | 85 in |
|---|---|
| Overall Length | 157 in |
| Overall Width | 60 in |
| Height - Top of ROPS/FOPS | 89 in |
Transmission
| Max Speed | 24.9 mph |
|---|
Production
| Series | 3600 Series |
|---|---|
| Years Manufactured | 1,987 – 1,990 |
