Massey Ferguson

5610

Tractor

Displacement
201 in³
Gross Power
100.0 hp
All tractors
Massey Ferguson 5610 Tractor
1 / 5
Image 1 of 5
Image: masseyferguson.com

Specifications

19 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity42.0 gal

Engine

Engine specifications
Engine ModelAGCO Power
Displacement201 in³
Gross Power100.0 hp
Number of Cylinders3
AspirationTurbocharged
Engine Make33 AWI HD
PTO Power75.0 hp

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity15.0 gal/min
Number of Remote Control Valves—

Dimensions

Dimensions specifications
Height - Top of Cab109 in
Wheelbase97 in
Overall Length168 in
Width Outside Frame80 in

Transmission

Transmission specifications
Max Speed16.0 mph
Transmission TypeDyna-4 transmission with speed matching

Production

Production specifications
Series5600 Series
Years Manufactured—

Power Take-Off (PTO)

Power Take-Off (PTO) specifications
Power Take-Off(PTO) TypeIndependent electronically engaged
