Massey Ferguson
Macdon
M100
Tractor
20 specifications
Massey Ferguson
7622
- Operating Weight
- 15,801 lb
- Displacement
- 452 in³
- Power Measured @
- 2,100 rpm
- Gross Power
- 200.0 hp
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 15,801 lb |
|---|---|
| Fuel Capacity | 114.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 13,999 lb |
| Hydraulic System Fluid Capacity | 26.4 gal |
| DEF tank capacity | 14.0 gal |
Engine
| Displacement | 452 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 200.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged and air-to-air aftercooled |
| PTO Power | 165.0 hp |
Hydraulic System
| Pump Flow Capacity | 24.3 gal/min |
|---|---|
| Number of Remote Control Valves | 3 |
| Hydraulic System Type | Closed Center Load Sensing |
| Maximum operating pressure | 2,900 psi |
Dimensions
| Wheelbase | 119 in |
|---|---|
| Overall Length | 204 in |
| Height - Top of ROPS/FOPS | 121 in |
Transmission
| Max Speed | 25.6 mph |
|---|---|
| Number of Forward Gears | 16 |
| Transmission Type | Dyna-4 |
Production
| Series | 7600 Series |
|---|---|
| Years Manufactured | 2,013 – 2,014 |
Power Take-Off (PTO)
| PTO speed | 1,000 rpm |
|---|
