Massey Ferguson

9220

Mower Conditioner

Operating Weight w/o Attachment
8,100 lb
Max Speed
11.0 mph
Power
85.0 hp
All mower conditioners/windrowers
Massey Ferguson 9220 Mower Conditioner
1 / 5
Image 1 of 5
Image: farmandplant.ie

Specifications

18 data points

Operating Specifications

Operating Specifications specifications
Operating Weight w/o Attachment8,100 lb
Fuel Capacity80.0 gal
Front Tire Size18.4 x 26 Turf Tread
Rear Tire Size14.1 x 16.1

Engine

Engine specifications
Power85.0 hp
AspirationTurbocharged
Engine ModelB3.3T

Dimensions

Dimensions specifications
Height - Top of Cab132 in
Wheelbase141 in
Overall Width148 in
Front Wheel Tread Width128 in
Rear Wheel tread Width - max120 in
Rear Wheel Tread Width - min85 in
Length w/ Header258 in

Transmission

Transmission specifications
Max Speed11.0 mph
Transmission TypeHydrostatic with planetary final reduction
Number of Reverse Gears1
Number of Forward Gears1
