Massey Ferguson
Fendt
209 VA
Tractor
19 specifications
Massey Ferguson
MF 275
- Operating Weight
- 5,573 lb
- Displacement
- 248 in³
- Power Measured @
- 2,200 rpm
- Gross Power
- 72.0 hp
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 5,573 lb |
|---|---|
| Fuel Capacity | 21.2 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,049 lb |
| Turning Radius | 143 in |
| Alternator Supplied Amperage | 45 A |
| Tire Size Front - 2wd / 4wd | 7.50-16 6PR |
| Cooling System Fluid Capacity | 3.8 gal |
| Hydraulic System Fluid Capacity | 10.6 gal |
Engine
| Engine Model | 4.41 |
|---|---|
| Displacement | 248 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 72.0 hp |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 195 lb-ft |
| PTO Power | 62.9 hp |
Hydraulic System
| Pump Flow Capacity | 4.5 gal/min |
|---|---|
| Relief Valve Setting | 3,002 psi |
Dimensions
| Wheelbase | 81 in |
|---|---|
| Overall Length | 12 in |
| Overall Width | 79 in |
| Height | 100 in |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Transmission Type | 8 speed sliding spur |
| Number of Reverse Gears | 2 |
Tires & Wheels
| Rear Tires Size | 16.9-30 6PR |
|---|
