Massey Ferguson
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 4,850 lb |
|---|---|
| Fuel Capacity | 12.6 gal |
| Cooling System Fluid Capacity | 2.7 gal |
| Hydraulic System Fluid Capacity | 8.8 gal |
Engine
| Engine Model | 4.248 |
|---|---|
| Power Measured @ | 2,250 rpm |
| Gross Power | 75.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 69.5 hp |
Hydraulic System
| Pump Flow Capacity | 4.3 gal/min |
|---|---|
| Relief Valve Pressure | 2,785 psi |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 76 in |
| Overall Length | 12 in |
| Tire Size | Front 6.00 -16 (6 PR) Rear 12.4/11-28(6PR) |
| Width Outside Frame | 66 in |
Transmission
| Max Speed | 17.8 mph |
|---|---|
| Number of Forward Gears | 8 |
| Transmission Type | Sliding Spur |
| Number of Reverse Gears | 2 |
