Massey Ferguson

MF 415

Tractor

Displacement
153 in³
Power Measured @
2,250 rpm
Gross Power
46.0 hp
All tractors
Massey Ferguson MF 415 Tractor
1 / 5
Image 1 of 5
Image: tractordata.site

Specifications

23 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity15.1 gal
3 Point Hitch Lift Capacity @ 24 inches4,630 lb
Tire Size Front - 2wd / 4wd6.00-16

Engine

Engine specifications
Engine ModelAD3.152
Displacement153 in³
Power Measured @2,250 rpm
Gross Power46.0 hp
Aspirationnatural
Torque Measured @1,350 rpm
Max Torque133 lb-ft
PTO Power39.7 hp

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity4.5 gal/min
Relief Valve Pressure3,046 psi
Relief Valve Setting3,046 psi

Dimensions

Dimensions specifications
Height - Top of Cab97 in
Wheelbase79 in
Overall Length13 in
Tire Sizefront 12.5/80-18 rear 14.9-24
Height - Top of ROPS/FOPS97 in
Height83 in

Transmission

Transmission specifications
Number of Forward Gears8
Number of Reverse Gears2

Tires & Wheels

Tires & Wheels specifications
Rear Tires Size14.9-24
