Mccormick
Fendt
209 VA
Tractor
19 specifications
Mccormick
C95 Max
- Operating Weight
- 7,341 lb
- Displacement
- 269 in³
- Power Measured @
- 2,200 rpm
- Gross Power
- 91.9 hp
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 7,341 lb |
|---|---|
| Fuel Capacity | 27.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,732 lb |
| 3 Point Hitch Type | Cat 2 |
| Turning Radius | 162 in |
Engine
| Engine Model | 1104C-44T |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 91.9 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 21.8 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
| Relief Valve Pressure | 2,611 psi |
Dimensions
| Height - Top of Cab | 101 in |
|---|---|
| Wheelbase | 91 in |
| Overall Length | 14 in |
| Tire Size | front 13.6-24 rear 16.9-34 |
| Width Outside Frame | 69 in |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Number of Forward Gears | 24 |
| Transmission Type | mec. rev. shuttle |
| Number of Reverse Gears | 12 |
Axles
| Final Drive | epicyclic |
|---|
