Mccormick
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 5,556 lb |
|---|---|
| Fuel Capacity | 15.9 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 3,880 lb |
| 3 Point Hitch Type | 1 |
| Turning Radius | 126 in |
| Alternator Supplied Amperage | 50 A |
| Operating Voltage | 12 V |
Engine
| Displacement | 203 in³ |
|---|---|
| Power Measured @ | 2,500 rpm |
| Gross Power | 55.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 50.0 hp |
Hydraulic System
| Pump Flow Capacity | 9.5 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
Dimensions
| Height - Top of Cab | 96 in |
|---|---|
| Wheelbase | 83 in |
| Overall Length | 12 in |
| Width Outside Frame | 56 in |
Transmission
| Max Speed | 17.3 mph |
|---|---|
| Number of Forward Gears | 16 |
| Transmission Type | synchro shuttle |
| Number of Reverse Gears | 16 |
