Mccormick
New Holland
TC35
Tractor
21 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 2,646 lb |
|---|---|
| Fuel Capacity | 8.5 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,619 lb |
| 3 Point Hitch Type | 1 |
| Turning Radius | 101 in |
| Alternator Supplied Amperage | 50 A |
| Operating Voltage | 12 V |
Engine
| Displacement | 101 in³ |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 32.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 26.0 hp |
Hydraulic System
| Pump Flow Capacity | 8.0 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 91 in |
| Wheelbase | 66 in |
| Overall Length | 10 in |
Transmission
| Max Speed | 16.5 mph |
|---|---|
| Number of Forward Gears | 12 |
| Transmission Type | synchro |
| Number of Reverse Gears | 12 |
