Mccormick
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 6,724 lb |
|---|---|
| Fuel Capacity | 23.8 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 7,496 lb |
| 3 Point Hitch Type | Cat 2 |
Engine
| Engine Model | 804C-33T |
|---|---|
| Displacement | 203 in³ |
| Gross Power | 69.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 15.1 gal/min |
|---|---|
| Number of Remote Control Valves | 4 |
Dimensions
| Height - Top of Cab | 95 in |
|---|---|
| Wheelbase | 84 in |
| Overall Length | 13 in |
| Tire Size | 380/70R28 |
| Width Outside Frame | 69 in |
Transmission
| Number of Forward Gears | 30 |
|---|---|
| Transmission Type | mech. reverse shuttle |
| Number of Reverse Gears | 30 |
