Michigan
Liugong
CLG856 II
Wheel Loader
36 specifications
Michigan
L190
- Operating Weight
- 59,781 lb
- Bucket Capacity - heaped
- 5.79 yd³
- Gross Power
- 322.0 hp
- Net Power
- 290.0 hp
1 / 5
Image 1 of 5
Specifications
45 data points
Operating Specifications
| Operating Weight | 59,781 lb |
|---|---|
| Fuel Capacity | 115.2 gal |
| Tire Size | 29.5-25 |
| Hydraulic System Fluid Capacity | 85.1 gal |
| Static Tipping Weight | 42,260 lb |
| Operating Voltage | 24 V |
| Turning Radius | 302 in |
| Engine Oil Fluid Capacity | 9.1 gal |
| Rear Axle Oscillation | 22 ° |
| Alternator Supplied Amperage | 100 A |
| Front Axle/Diff Fluid Capacity | 9.1 gal |
| Rear Axle/Diff Fluid Capacity | 9.1 gal |
| Cooling System Fluid Capacity | 20.0 gal |
| Transmission Fluid Capacity | 12.5 gal |
Engine
| Engine Model | NTA 855C335 |
|---|---|
| Displacement | 855 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 322.0 hp |
| Net Power | 290.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbo + aftercooled |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 35.5 gal/min |
|---|---|
| Raise Time | 7.0 s |
| Lower Time | 5.0 s |
| Dump Time | 3.0 s |
| Relief Valve Setting | 2,750 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Height - Top of Cab | 149 in |
| Wheelbase | 138 in |
| Width Over Tires | 124 in |
| Reach at Max Lift and Dump | 55 in |
| Length with Bucket on Ground | 360 in |
| Hinge Pin - Max Height | 176 in |
Transmission
| Max Speed - Forward | 22.4 mph |
|---|---|
| Max Speed - Reverse | 22.4 mph |
| Transmission Type | Clark 4425-200 |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 5.79 yd³ |
|---|---|
| Bucket Capacity - struck | 4.90 yd³ |
| Dump Clearance at Max Raise | 126 in |
| Breakout Force | 58,563 lb |
| Bucket Width | 131 in |
