New Holland
Komatsu
D87E-3
Crawler Dozer
41 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 86,201 lb |
|---|---|
| Fuel Capacity | 177.0 gal |
| Cooling System Fluid Capacity | 9.8 gal |
| Final Drives Fluid Capacity | 9.6 gal |
| Engine Oil Capacity | 9.3 gal |
| Hydraulic Fluid Capacity | 38.4 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
Engine
| Engine Model | QSM11 |
|---|---|
| Displacement | 660 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 300.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged aftercooled |
Hydraulic System
| Pump Flow Capacity | 92.5 gal/min |
|---|---|
| Relief Valve Pressure | 2,901 psi |
| Pump Type | variable displacement piston |
Dimensions
| Length of Track on Ground | 128 in |
|---|---|
| Width Over Tracks | 109 in |
| Length w/ Blade | 250 in |
| Length w/o Blade | 209 in |
Transmission
| Max Speed - Forward | 6.6 mph |
|---|---|
| Max Speed - Reverse | 7.9 mph |
| Transmission Type | Full PowerShift CounterShaft Constant Mesh |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 13 psi |
|---|---|
| Track Gauge | 85 in |
| Number of Track Rollers per Side | 7 |
| Number of Shoes per Side | 44 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 24 in |
| Ground Contact Area | 61,326 in³ |
Standard Blade
| Width | 157 in |
|---|---|
| Height | 67 in |
| Capacity | 11.99 yd³ |
| Blade Angle (both directions) | 13 ° |
