New Holland
Caterpillar
D3K LGP
Crawler Dozer
35 specifications
New Holland
D95B LT
- Operating Weight
- 19,626 lb
- Max Speed - Forward
- 5.5 mph
- Gross Power
- 99.0 hp
- Net Power
- 96.0 hp
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 19,626 lb |
|---|---|
| Fuel Capacity | 50.0 gal |
| Cooling System Fluid Capacity | 6.0 gal |
| Final Drives Fluid Capacity | 3.8 gal |
| Engine Oil Capacity | 3.3 gal |
| Hydraulic Fluid Capacity | 20.0 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 A |
Engine
| Engine Model | FPT 445TA/E66 |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 99.0 hp |
| Net Power | 96.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 295 lb-ft |
| Make | New Holland |
Hydraulic System
| Pump Flow Capacity | 20.3 gal/min |
|---|---|
| Pump Type | Geaar |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 110 in |
| Length of Track on Ground | 94 in |
| Width Over Tracks | 102 in |
| Length w/ Blade | 168 in |
| Length w/o Blade | 130 in |
Transmission
| Max Speed - Forward | 5.5 mph |
|---|---|
| Max Speed - Reverse | 5.5 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 10 |
| Number of Reverse Gears | 10 |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 62 in |
| Number of Track Rollers per Side | 1 |
| Number of Shoes per Side | 40 |
| Number of Carrier Rollers per Side | 7 |
| Standard Shoe Size | 18 in |
| Track Pitch | 7 in |
Standard Blade
| Width | 98 in |
|---|---|
| Height | 36 in |
| Capacity | 2.20 yd³ |
| Blade Angle (both directions) | 25 ° |
