New Holland
Mitsubishi
BD2HS-HB1
Crawler Dozer
17 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Fuel Capacity | 71.4 gal |
|---|---|
| Cooling System Fluid Capacity | 7.4 gal |
| Final Drives Fluid Capacity | 2.7 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | 6BTAA5.9 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 150.0 hp |
| Net Power | 140.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 479 lb-ft |
Dimensions
| Length of Track on Ground | 101 in |
|---|
Transmission
| Max Speed - Forward | 6.8 mph |
|---|---|
| Max Speed - Reverse | 8.1 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 76 in |
| Number of Track Rollers per Side | 8 |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 22 in |
| Ground Contact Area | 5,089 in³ |
