New Holland
Daewoo
SOLAR 130LC V
Excavator
3 specifications
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight | 50,045 lb |
|---|---|
| Fuel Capacity | 85.9 gal |
| Hydraulic Pump Flow Capacity | 140.1 gal/min |
| Hydraulic System Fluid Capacity | 42.3 gal |
| Hydraulic System Relief Valve Pressure | 5,004 psi |
| Engine Oil Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 8.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
| Hydraulic Pump Type | 3 Variable Displacement Axial Piston |
| Tire Size | 10.00-20 |
Engine
| Engine Model | CNH F4BE0684A |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 166.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharger and charge air cooling |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 109 in |
| Overall Width | 9 in |
| Tail Swing Radius | 109 in |
| Upper Structure Clearance | 50 in |
| Overall Width - Outriggers Down | 173 in |
Transmission
| Max Travel Speed | 12.5 mph |
|---|---|
| Drawbar Pull | 29,225 lb |
Bucket
| Reference Bucket Capacity | 0.99 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.60 yd³ |
| Minimum Bucket Capacity | 0.71 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 51,629 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 229 in |
|---|---|
| Max Cutting Height | 403 in |
| Max Reach Along Ground | 366 in |
| Max Loading Height | 283 in |
| Shipping Length of Unit | 373 in |
| Shipping Height of Unit | 126 in |
| Max Vertical Wall Dig Depth | 163 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 240 in |
|---|---|
| Max Cutting Height | 406 in |
| Max Reach Along Ground | 376 in |
| Max Loading Height | 287 in |
| Shipping Height of Unit | 125 in |
| Shipping Length of Unit | 372 in |
| Max Vertical Wall Dig Depth | 166 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 252 in |
|---|---|
| Max Cutting Height | 414 in |
| Max Reach Along Ground | 388 in |
| Max Loading Height | 295 in |
| Shipping Height of Unit | 127 in |
| Shipping Length of Unit | 371 in |
| Max Vertical Wall Dig Depth | 176 in |
