New Holland
Daedong
EX35(CR)
Tractor
22 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 6,125 lb |
|---|---|
| Fuel Capacity | 37.0 gal |
| 3 Point Hitch Type | Cat II |
| Alternator Supplied Amperage | 55 A |
| Operating Voltage | 12 V |
| Tire Size Front - 2wd / 4wd | 18.4x30R1 tires |
| Cooling System Fluid Capacity | 3.5 gal |
| Engine Oil Capacity | 3.0 gal |
Engine
| Displacement | 305 in³ |
|---|---|
| Gross Power | 108.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| PTO Power | 90.0 hp |
Hydraulic System
| Pump Flow Capacity | 18.5 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
| Relief Valve Pressure | 2,600 psi |
| Relief Valve Setting | 2,600 psi |
Dimensions
| Height - Top of Cab | 101 in |
|---|---|
| Tire Size | 18.4x30 R1 |
| Height - Top of ROPS/FOPS | 101 in |
| Height | 81 in |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Number of Reverse Gears | 2 |
Tires & Wheels
| Rear Tires Size | 18.4x30R1 tires |
|---|
