New Holland
Branson
2400
Tractor
18 specifications
New Holland
TC35D
- Operating Weight
- 3,252 lb
- Displacement
- 101 in³
- Power Measured @
- 2,600 rpm
- Gross Power
- 35.0 hp
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 3,252 lb |
|---|---|
| Fuel Capacity | 13.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,025 lb |
| Turning Radius | 110 in |
Engine
| Displacement | 101 in³ |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 35.0 hp |
| Number of Cylinders | 3 |
| PTO Power | 29.1 hp |
Hydraulic System
| Pump Flow Capacity | 14.9 gal/min |
|---|
Dimensions
| Ground Clearance | 14 in |
|---|---|
| Height - Top of Cab | 96 in |
| Wheelbase | 74 in |
| Overall Length | 11 in |
| Tire Size | Front 7x16 Rear 13.6x24 |
| Width Outside Frame | 62 in |
Transmission
| Max Speed | 14.3 mph |
|---|---|
| Transmission Type | Dualpower |
