New HollandNew Holland
TC35
Tractor
21 specifications
New Holland
TC45D
- Operating Weight
- 3,417 lb
- Displacement
- 135 in³
- Power Measured @
- 2,600 rpm
- Gross Power
- 45.0 hp
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 3,417 lb |
|---|---|
| Fuel Capacity | 13.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,330 lb |
| Turning Radius | 110 in |
Engine
| Displacement | 135 in³ |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 45.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 37.8 hp |
Hydraulic System
| Pump Flow Capacity | 14.9 gal/min |
|---|
Dimensions
| Ground Clearance | 14 in |
|---|---|
| Height - Top of Cab | 96 in |
| Wheelbase | 74 in |
| Overall Length | 11 in |
| Tire Size | Front 7x16 Rear 13.6x24 |
| Width Outside Frame | 62 in |
Transmission
| Max Speed | 13.6 mph |
|---|---|
| Transmission Type | Dualpower |
