New Holland
TS110
- Operating Weight
- 7,308 lb
- Displacement
- 305 in³
- Power Measured @
- 2,070 rpm
- Gross Power
- 110.0 hp
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 7,308 lb |
|---|---|
| Fuel Capacity | 42.1 gal |
| Turning Radius | 145 in |
| Engine Oil Capacity | 3.0 gal |
Engine
| Displacement | 305 in³ |
|---|---|
| Power Measured @ | 2,070 rpm |
| Gross Power | 110.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Engine Make | New Holland |
| PTO Power | 89.9 hp |
Hydraulic System
| Pump Flow Capacity | 9.3 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
| Maximum operating pressure | 2,495 psi |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 93 in |
| Overall Length | 150 in |
| Overall Width | 80 in |
| Height - Top of ROPS/FOPS | 108 in |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Number of Forward Gears | 12 |
| Transmission Type | Manual / Partially synchronized |
| Number of Reverse Gears | 12 |
