Rammax
RW3005S
Walk-Behind Compactor
16 specifications
1 / 5
Image 1 of 5
Specifications
16 data points
Operating Specifications
| Operating Weight | 10,582 lb |
|---|---|
| Max Speed | 6.3 mph |
| Fuel Capacity | 17.2 gal |
| Hydraulic System Fluid Capacity | 36.8 gal |
Engine
| Engine Model | V3300 |
|---|---|
| Power Measured @ | 2,650 rpm |
| Gross Power | 68.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Height - Top of Cab | 98 in |
|---|---|
| Width Over Tires | 61 in |
| Overall Length w/o Blade | 159 in |
Drum
| Drum Width | 55 in |
|---|---|
| Drum Diameter | 42 in |
| Centrifugal Force - High | 22,481 lb |
| Nominal Amplitude - High | 0 in |
| Vibration Frequency 1 | 34 vpm |
