Specifications
24 data points
Operating Specifications
| Operating Weight | 13,228 lb |
|---|---|
| Fuel Capacity | 24.4 gal |
| Hydraulic System Fluid Capacity | 23.8 gal |
| Tire Size | 400/70-20'' PR14 |
Engine
| Gross Power | 81.5 hp |
|---|---|
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 21.2 gal/min |
|---|---|
| Pump Type | fixed displacement |
| Relief Valve Pressure | 3,916 psi |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 104 in |
| Width Over Tires | 79 in |
| Overall Height | 81 in |
| Length to Fork Face | 185 in |
| Turning Radius Outside Tires | 159 in |
Transmission
| Max Speed - Forward | 21.8 mph |
|---|---|
| Max Speed - Reverse | 21.8 mph |
| Transmission Type | hydrostatic 2-speed mechanical gearbox |
Lift System
| Max Lift Capacity | 6,614 lb |
|---|---|
| Max Forward Reach | 150 in |
| Max Lift Height | 270 in |
| Max Load at Max Height | 5,512 lb |
| Max Load at Max Reach | 2,756 lb |
