TerexTerex
ATT 400
All Terrain Crane
25 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Tire Size | 14.00 R 25 |
|---|---|
| Carrier Fuel Capacity | 132.1 gal |
| Operating Voltage | 24 V |
| Number of Axels | 5 |
| Upper Structure Fuel Capacity | 52.9 gal |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Transport Width | 109 in |
| Transport Height | 157 in |
| Transport Length | 595 in |
| Width w/ Outriggers Extended | 296 in |
| Upper Structure Tail Swing Radius | 167 in |
| Carrier Length | 472 in |
Transmission
| Max Speed - Forward | 50.0 mph |
|---|---|
| Max Speed - Reverse | 4.0 mph |
| Transmission Type | ZF Transmatik system |
Boom
| Number of Sections | 5 |
|---|---|
| Max Height @ Max Raise Angle - no jib | 3,035 in |
| Min Height @ Max Raise Angle | 588 in |
| Max Elevating Angle | 81 ° |
CARRIER ENGINE
| Gross Power | 496.2 hp |
|---|---|
| Max Torque | 1,490 lb-ft |
| Torque Measured @ | 1,600 rpm |
| Make | Terex |
| Power Measured @ | 2,100 rpm |
UPPER STRUCTURE ENGINE
| Gross Power | 150.2 hp |
|---|---|
| Make | Terex |
| Max Torque | 398 lb-ft |
| Torque Measured @ | 1,400 rpm |
| Power Measured @ | 2,200 rpm |
