Tong Yang Mooslan
New Holland
TC35
Tractor
21 specifications
Tong Yang Mooslan
T353HST
- Operating Weight
- 3,065 lb
- Displacement
- 107 in³
- Power Measured @
- 2,700 rpm
- Gross Power
- 35.0 hp
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 3,065 lb |
|---|---|
| Fuel Capacity | 9.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 1,764 lb |
| 3 Point Hitch Type | Cat I |
| Turning Radius | 95 in |
| Alternator Supplied Amperage | 50 A |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 1.9 gal |
| Hydraulic System Fluid Capacity | 9.3 gal |
| Engine Oil Capacity | 1.6 gal |
Engine
| Engine Model | S4L2 |
|---|---|
| Displacement | 107 in³ |
| Power Measured @ | 2,700 rpm |
| Gross Power | 35.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 26.0 hp |
Hydraulic System
| Pump Flow Capacity | 10.9 gal/min |
|---|---|
| Number of Remote Control Valves | 1 |
Dimensions
| Height - Top of Cab | 95 in |
|---|---|
| Wheelbase | 67 in |
| Overall Length | 11 in |
| Tire Size | front 27-10.5-15 R4 rear 12.5-20 R4 |
| Width Outside Frame | 53 in |
Transmission
| Max Speed | 16.2 mph |
|---|---|
| Number of Forward Gears | — |
| Transmission Type | hst |
