Toyota
Cukurova
CF25FX
Forklift
Specifications pending
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Max Speed | 13.7 mph |
|---|---|
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | pneumatic |
Engine
| Engine Model | V6 4.3 L LPG |
|---|---|
| Power Measured @ | 2,350 rpm |
| Torque Measured @ | 1,200 rpm |
| Power | 90.0 hp |
| Fuel Type | Gas |
| Torque | 217 lb-ft |
Dimensions
| Wheelbase | 79 in |
|---|---|
| Overall Width | 57 in |
| Turning Radius | 109 in |
| Length to Fork Face | 124 in |
| Height to Top of Overhead Guard | 90 in |
| Right Angle Stack | 131 in |
Mast
| Load Capacity | 10,000 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.0 mph |
