Toyota
Cukurova
CF25FX
Forklift
Specifications pending
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Max Speed | 11.5 mph |
|---|---|
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Pneumatic |
| Fuel Capacity | 12.0 gal |
Engine
| Engine Model | 4Y - ECS |
|---|---|
| Displacement | 136 in³ |
| Power Measured @ | 2,570 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 2,100 rpm |
| Engine Make | TOYOTA |
| Power | 51.0 hp |
| Fuel Type | Gasoline |
| Torque | 118 lb-ft |
| Battery | 12 V |
Hydraulic System
| Main pump flow standard | 17.0 gal/min |
|---|---|
| Maximum operating pressure | 2,275 psi |
Dimensions
| Ground Clearance | 4 in |
|---|---|
| Wheelbase | 59 in |
| Overall Width | 43 in |
| Turning Radius | 77 in |
| Overall Height - mast lowered | 85 in |
| Length to Fork Face | 90 in |
| Gradeability | 45.0 % |
| Height to Top of Overhead Guard | 83 in |
| Max Fork Height | 132 in |
| Right Angle Stack | 93 in |
| Free lift | 6 in |
Transmission
| Transmission Type | Powershift |
|---|
Brakes & Steering
| Service brake | Hydraulic |
|---|---|
| Parking brake | Mechanical |
Tires & Wheels
| Rear Tires Size | 5.00-8-8PR |
|---|---|
| Front Tires Size | 6.50-10-10PR |
Mast
| Load Capacity | 2,976 lb |
|---|---|
| Load Center | 24 in |
| Lift Speed | 1.5 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 11 ° |
| Lower Speed | 1.1 mph |
| Max Fork Spread | 36 in |
