Ursus
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 4,674 lb |
|---|---|
| Fuel Capacity | 15.4 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,932 lb |
| Alternator Supplied Amperage | 55 A |
| Operating Voltage | 12 V |
| Tire Size Front - 2wd / 4wd | 6.00-16 6PR |
| Cooling System Fluid Capacity | 2.7 gal |
| Hydraulic System Fluid Capacity | 9.6 gal |
| Engine Oil Capacity | 1.8 gal |
Engine
| Engine Model | 3250 |
|---|---|
| Displacement | 153 in³ |
| Power Measured @ | 2,250 rpm |
| Gross Power | 48.7 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 125 lb-ft |
| PTO Power | 40.5 hp |
Hydraulic System
| Pump Flow Capacity | 7.0 gal/min |
|---|---|
| Relief Valve Setting | 2,321 psi |
Dimensions
| Wheelbase | 83 in |
|---|---|
| Overall Length | 11 in |
| Overall Width | 52 in |
| Height - Top of ROPS/FOPS | 91 in |
Transmission
| Max Speed | 16.9 mph |
|---|---|
| Number of Forward Gears | 8 |
| Transmission Type | mechanical with sliding gears |
| Number of Reverse Gears | 2 |
Tires & Wheels
| Rear Tires Size | 12.4-28 |
|---|
