Ursus
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 7,011 lb |
|---|---|
| Fuel Capacity | 21.2 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 4,850 lb |
| Alternator Supplied Amperage | 55 A |
| Operating Voltage | 12 V |
| Tire Size Front - 2wd / 4wd | 7.50-16 |
| Cooling System Fluid Capacity | 4.4 gal |
| Hydraulic System Fluid Capacity | 11.1 gal |
| Engine Oil Capacity | 1.9 gal |
Engine
| Engine Model | 4390 |
|---|---|
| Displacement | 236 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 78.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 193 lb-ft |
| PTO Power | 61.0 hp |
Hydraulic System
| Pump Flow Capacity | 7.0 gal/min |
|---|---|
| Relief Valve Setting | 2,321 psi |
Dimensions
| Wheelbase | 88 in |
|---|---|
| Overall Length | 12 in |
| Overall Width | 79 in |
| Height - Top of ROPS/FOPS | 101 in |
Transmission
| Max Speed | 17.9 mph |
|---|---|
| Number of Forward Gears | 8 |
| Transmission Type | mechanical with sliding gears |
| Number of Reverse Gears | 2 |
Tires & Wheels
| Rear Tires Size | 16.9-30 |
|---|
