Ursus
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 7,716 lb |
|---|---|
| Fuel Capacity | 21.2 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 4,850 lb |
| 3 Point Hitch Type | 2 cat. ISO |
| Alternator Supplied Amperage | 55 A |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 4.4 gal |
| Hydraulic System Fluid Capacity | 11.7 gal |
| Engine Oil Capacity | 1.9 gal |
Engine
| Engine Model | 4390 |
|---|---|
| Displacement | 236 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 78.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 61.0 hp |
Hydraulic System
| Pump Flow Capacity | 7.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,321 psi |
Dimensions
| Height - Top of Cab | 101 in |
|---|---|
| Wheelbase | 91 in |
| Overall Length | 12 in |
| Tire Size | front 9.5-24 rear 16.9-14-34 |
| Width Outside Frame | 79 in |
Transmission
| Max Speed | 17.9 mph |
|---|---|
| Number of Forward Gears | 8 |
| Transmission Type | mechanical with sliding gears |
| Number of Reverse Gears | 2 |
Axles
| Final Drive | spiral bevel gear |
|---|
