Valtra
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 5,677 lb |
|---|---|
| Fuel Capacity | 15.9 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,457 lb |
| Turning Radius | 131 in |
| Tire Size Front - 2wd / 4wd | 6.5-16 |
Engine
| Engine Model | Deutz F3L 913 |
|---|---|
| Power Measured @ | 2,350 rpm |
| Net Power | 76.0 hp |
| Number of Cylinders | 3 |
| Aspiration | naturally aspirated |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 131 lb-ft |
Hydraulic System
| Pump Flow Capacity | 16.7 gal/min |
|---|---|
| Number of Remote Control Valves | 1 |
Dimensions
| Wheelbase | 78 in |
|---|---|
| Overall Length | 12 in |
| Height - Top of ROPS/FOPS | 102 in |
| Height | 95 in |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Number of Forward Gears | 24 |
| Transmission Type | 24+24 speeds with splitter and synchronized forward reverse shuttle |
| Number of Reverse Gears | 24 |
Tires & Wheels
| Rear Tires Size | 14.9R28 |
|---|
