Versatile
Apache
AS1220
Sprayer
21 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Rinse Tank Capacity | 120.0 gal |
|---|---|
| Hydraulic Fluid Capacity | 35.1 gal |
Engine
| Engine Model | QSB6.7 |
|---|---|
| Displacement | 409 in³ |
| Gross Power | 275.0 hp |
| Torque Measured @ | 1,500 rpm |
| Engine Make | Cummins |
| Emission Tier Level | Tier 3 Stage IIIA |
| Gross Torque | 730 lb-ft |
Dimensions
| Wheelbase | 166 in |
|---|---|
| Overall Length | 324 in |
| Tire Size | 380/90R46 |
Transmission
| Max Speed | 35.5 mph |
|---|---|
| Transmission Type | Allison 3000RDS |
Boom
| Max Boom Width | 1,441 in |
|---|---|
| Min Boom Width | 961 in |
| Max Adjustable Height | 72 in |
| Min Adjustable Height | 25 in |
