Yanmar
Tong Yang Mooslan
HL6060C
Combine
15 specifications
Yanmar
AW695K
- Operating Weight w/o Attachment
- 8,642 lb
- Fuel Capacity
- 26.5 gal
- Displacement
- 269 in³
- Power
- 93.8 hp
1 / 5
Image 1 of 5
Specifications
16 data points
Operating Specifications
| Operating Weight w/o Attachment | 8,642 lb |
|---|---|
| Fuel Capacity | 26.5 gal |
| Transmission Type | Hydrostatic Transmission |
Engine
| Engine Model | 4TNV106T |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,350 rpm |
| Power | 93.8 hp |
Dimensions
| Overall Length | 186 in |
|---|---|
| Width Over Tires | 83 in |
| Height to Top of Isomount Cab | 104 in |
Grain Handling
| Grain Tank Capacity | 515.7 gal |
|---|---|
| Unloading Auger Length | 178 in |
Threshing
| Rotor Diameter | 8 in |
|---|---|
| Rotor Length | 9 in |
| Rotor Speed - High | 1,530 rpm |
| Rotor Speed - Low | 1,530 rpm |
