Yanmar
Iseki
TH4260 Mech
Tractor
15 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Tire Size Front - 2wd / 4wd | 10 â?? 16.5 in |
|---|
Engine
| Displacement | 134 in³ |
|---|---|
| Power Measured @ | 2,700 rpm |
| Gross Power | 48.5 hp |
| Number of Cylinders | 4 |
| PTO Power | 37.5 hp |
| Bore | 4 in |
| Stroke | 4 in |
| Air cleaner | Dual dry |
| Cooling system | Liquid cooled |
| Lubrication | Full pressure |
Hydraulic System
| Pump Flow Capacity | 12.7 gal/min |
|---|---|
| Hydraulic System Type | Open center |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 14 in |
|---|---|
| Wheelbase | 864 in |
| Overall Length | 126 in |
| Overall Width | 863 in |
| Weight | 3,499 lb |
Transmission
| Number of Forward Gears | 9 |
|---|---|
| Transmission Type | Synchronized shuttle |
| Number of Reverse Gears | 9 |
Fluid Capacities
| Fuel Tank | 11.3 gal |
|---|---|
| Engine Oil | 1.4 gal |
| Cooling system | 1.2 gal |
| Transmission | 7.0 gal |
| Front axle | 462 in³ |
Tires & Wheels
| Rear Tires Size | 17.5 â?? 24 in |
|---|
Production
| Series | Ex Series |
|---|---|
| Years Manufactured | — |
3-Point Hitch
| Lift capacity @ 24in. (ASAE) | 2,464 lb |
|---|---|
| 3-point hitch | Category 1 |
Power Take-Off (PTO)
| PTO type | Continuous live |
|---|---|
| PTO speed rear | 547 rpm |
