Yanmar
Iseki
TH4260 HST
Tractor
13 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Tire Size Front - 2wd / 4wd | 8 â?? 16 in |
|---|
Engine
| Displacement | 134 in³ |
|---|---|
| Power Measured @ | 2,700 rpm |
| Gross Power | 45.0 hp |
| Number of Cylinders | 4 |
| PTO Power | 32.5 hp |
| Bore | 4 in |
| Stroke | 4 in |
| Air cleaner | Dual element |
| Cooling system | Liquid cooled |
| Lubrication | Full pressure |
Hydraulic System
| Pump Flow Capacity | 9.0 gal/min |
|---|---|
| Hydraulic System Type | Open center |
| Pump Type | Dual gear |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Wheelbase | 898 in |
| Overall Length | 124 in |
| Overall Width | 834 in |
| Weight | 3,585 lb |
Fluid Capacities
| Fuel Tank | 11.9 gal |
|---|---|
| Engine Oil | 1.5 gal |
| Cooling system | 1.5 gal |
| Transmission | 8.7 gal |
| Front axle | 536 in³ |
Tires & Wheels
| Rear Tires Size | 14.9 â?? 24 in |
|---|
Production
| Series | Lx Series |
|---|---|
| Years Manufactured | — |
3-Point Hitch
| Lift capacity @ 24in. (ASAE) | 2,760 lb |
|---|---|
| 3-point hitch | Telescopic Category 1 |
Power Take-Off (PTO)
| PTO type | Electro-hydraulic independent |
|---|---|
| PTO speed rear | 540 rpm |
