Yanmar
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 3,880 lb |
|---|---|
| Fuel Capacity | 12.7 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 2,756 lb |
| 3 Point Hitch Type | Category 1 |
| Cooling System Fluid Capacity | 1.6 gal |
| Engine Oil Capacity | 1.8 gal |
Engine
| Engine Model | 4TNV88C |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 46.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Naturally aspirated |
| Engine Make | Yanmar |
| PTO Power | 39.5 hp |
| Stroke | 4 in |
| Bore | 4 in |
| Alternator | 55 A |
Hydraulic System
| Pump Flow Capacity | 5.8 gal/min |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 76 in |
| Overall Length | 131 in |
| Overall Height | 96 in |
| Width | 71 in |
Transmission
| Max Speed - Reverse | 18.0 mph |
|---|
Production
| Series | YT3 Series |
|---|---|
| Years Manufactured | — |
