Chetra
Komatsu
D65PX-17
Crawler Dozer
27 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 97,003 lb |
|---|
Engine
| Engine Model | M11-C330 |
|---|---|
| Displacement | 659 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 300.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 1,075 lb-ft |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Overall Length | 186 in |
| Overall Width | 192 in |
| Length of Track on Ground | 120 in |
| Overall Height | 283 in |
| Height to Top of Suspended Cab | 110 in |
| Lift Capacity at Max Reach | 19,621 lb |
Transmission
| Max Speed - Forward | 6.8 mph |
|---|---|
| Max Speed - Reverse | 8.6 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Track Gauge | 88 in |
|---|---|
| Shoe Size | 28 in |
Boom
| Max Lift Capacity | 144,623 lb |
|---|
