Agrale
New Holland
TC35
Tractor
21 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 2,513 lb |
|---|---|
| Fuel Capacity | 5.2 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 970 lb |
| Turning Radius | 85 in |
| Alternator Supplied Amperage | 55 A |
| Operating Voltage | 14 V |
| Tire Size Front - 2wd / 4wd | 4.00x15 |
| Hydraulic System Fluid Capacity | 2.7 gal |
| Engine Oil Capacity | 0.7 gal |
Engine
| Engine Model | M 93 |
|---|---|
| Displacement | 41 in³ |
| Power Measured @ | 2,750 rpm |
| Gross Power | 14.7 hp |
| Number of Cylinders | 1 |
| Torque Measured @ | 2,350 rpm |
| Max Torque | 29 lb-ft |
| PTO Power | 13.2 hp |
Hydraulic System
| Pump Flow Capacity | 3.6 gal/min |
|---|---|
| Number of Remote Control Valves | 6 |
| Relief Valve Setting | 1,741 psi |
Dimensions
| Wheelbase | 48 in |
|---|---|
| Overall Length | 8 in |
| Overall Width | 47 in |
| Height | 48 in |
Transmission
| Max Speed | 10.1 mph |
|---|---|
| Number of Forward Gears | 7 |
| Number of Reverse Gears | 3 |
Tires & Wheels
| Rear Tires Size | 8.3/8x24R1 |
|---|
