Airman

EW140B

Excavator

Net Power
88.0 hp
All excavators
Airman EW140B Excavator
1 / 5
Image 1 of 5
Image: industry-plaza.com

Specifications

28 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity66.1 gal
Hydraulic Pump Flow Capacity60.8 gal/min
Hydraulic System Fluid Capacity62.1 gal
Engine Oil Capacity4.0 gal
Cooling System Fluid Capacity5.7 gal
Operating Voltage24 V
Alternator Supplied Amperage80 A
Hydraulic Pump TypeAxial Piston Pump
Front Diff Fluid Capacity2.3 gal
Rear Diff Fluid Capacity3.0 gal

Engine

Engine specifications
Engine ModelD5D EBE2
Displacement293 in³
Gross Power92.0 hp
Net Power88.0 hp
AspirationTurbocharged
Net Torque409 lb-ft

Dimensions

Dimensions specifications
Ground Clearance13 in
Height - Top of Cab124 in
Wheelbase103 in
Overall Width8 in
Overall Width - Outriggers Down155 in

Transmission

Transmission specifications
Max Travel Speed18.7 mph
Transmission TypePowershift

Swing Mechanism

Swing Mechanism specifications
Swing Speed10 rpm

Boom/Stick Mobile Excavator Option 1

Boom/Stick Mobile Excavator Option 1 specifications
Max Digging Depth181 in
Max Cutting Height362 in
Max Reach Along Ground316 in
Max Vertical Wall Dig Depth122 in
