Airman

EW160B

Excavator

Net Power
103.0 hp
All excavators
Airman EW160B Excavator
1 / 5
Image 1 of 5
Image: porterce.com

Specifications

28 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity250.0 gal
Hydraulic Pump Flow Capacity63.5 gal/min
Hydraulic System Fluid Capacity68.7 gal
Engine Oil Capacity25.0 gal
Cooling System Fluid Capacity22.0 gal
Operating Voltage24 V
Alternator Supplied Amperage80 A
Hydraulic Pump TypeAxial Piston Pump
Front Diff Fluid Capacity2.3 gal
Rear Diff Fluid Capacity3.0 gal

Engine

Engine specifications
Engine ModelD6D EJE2
Displacement348 in³
Gross Power110.0 hp
Net Power103.0 hp
AspirationTurbocharged
Net Torque439 lb-ft

Dimensions

Dimensions specifications
Ground Clearance13 in
Height - Top of Cab124 in
Wheelbase103 in
Overall Width8 in
Overall Width - Outriggers Down155 in

Transmission

Transmission specifications
Max Travel Speed21.8 mph
Transmission TypePowershift

Swing Mechanism

Swing Mechanism specifications
Swing Speed10 rpm

Boom/Stick Mobile Excavator Option 1

Boom/Stick Mobile Excavator Option 1 specifications
Max Digging Depth202 in
Max Cutting Height347 in
Max Reach Along Ground328 in
Max Vertical Wall Dig Depth170 in
