Airman
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Fuel Capacity | 79.3 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 93.8 gal/min |
| Hydraulic System Fluid Capacity | 84.6 gal |
| Engine Oil Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
| Hydraulic Pump Type | Axial Piston Pump |
| Front Diff Fluid Capacity | 2.3 gal |
| Rear Diff Fluid Capacity | 2.8 gal |
Engine
| Engine Model | D6D EFE2 |
|---|---|
| Displacement | 348 in³ |
| Gross Power | 119.0 hp |
| Net Power | 112.0 hp |
| Aspiration | Turbocharged |
| Net Torque | 489 lb-ft |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 103 in |
| Overall Width | 8 in |
| Overall Width - Outriggers Down | 156 in |
Transmission
| Max Travel Speed | 21.8 mph |
|---|---|
| Transmission Type | Powershift |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 226 in |
|---|---|
| Max Cutting Height | 359 in |
| Max Reach Along Ground | 355 in |
| Max Vertical Wall Dig Depth | 166 in |
