ASVASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 7,450 lb |
|---|---|
| Max Speed - high range | 7.0 mph |
| Fuel Capacity | 13.0 gal |
| Hydraulic System Fluid Capacity | 28.1 gal |
| Cooling System Fluid Capacity | 2.3 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 A |
| Engine Oil Capacity | 1.7 gal |
Engine
| Engine Model | 4JB1 |
|---|---|
| Displacement | 171 in³ |
| Power Measured @ | 3,000 rpm |
| Gross Power | 70.0 hp |
| Aspiration | natural |
| Peak Torque | 128 lb-ft |
Hydraulic System
| Pump Flow | 25.0 gal/min |
|---|
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 83 in |
| Width Over Tracks | 70 in |
| Length - without Bucket | 113 in |
Undercarriage
| Ground Pressure | 3 psi |
|---|---|
| Length of Track on Ground | 79 in |
| Width of Track | 18 in |
| Number of Track Rollers per Side | 12 |
| Ground Contact Area | 2,826 in³ |
Loader
| Tipping Angle | 1,645 ° |
|---|---|
| Operating Load | 2,350 lb |
| Breakout Force | — |
