Ausa C150H Forklift
1 / 5
Image 1 of 5
Image: trucksdirectuk.co.uk

Specifications

24 data points

Engine

Engine specifications
Power24.8 hp
Torque—
EmissionsStage V - EPA Tier 4
No. of cylinders4
BrandKubota
Noise Level101 dB(A)

Hydraulic System

Hydraulic System specifications
Hydraulic circuit5.8 gal/min
Workiing pressure2,901 psi

Brakes & Steering

Brakes & Steering specifications
ServiceHydraulic sealed multi-disc
ParkingMechanical sealed multi-disc

General Specifications

General Specifications specifications
TransmissionHydrostatic
Empty weight5,952 lb
Load Capacity3,307 lb
Load capacity to 500 mm3,307 lb
Load capacity to 600 mm2,976 lb
Maximum lift157 in

Mast

Mast specifications
Carriage width50 in
Fork carriageFEM 2

Capacity

Capacity specifications
Fuel11.9 gal

Driving

Driving specifications
Max Speed12.4 mph
External turning radius101 in
Maximum gradient25.0 %
Tires10.0/75-15.3 6.00-9 / 23x8.5-12
Traction4x2 / 4x4 Compen®
